BY-3308P 8X9W RGB 3in1 Pixel LED BAR
BY-4308P 8X10W RGBW 4in1 Pixel LED BAR
BY-5308P 8X15W RGBWA 5in1 Pixel LED BAR
Light source and optics
8 x 15W RGBWA+UV 6in1 high power LED
Energy-saving LEDs employed, with more vivid colours and lower power consumption than traditional lamps
Colour synthesis: 6in1 colour mixing (>16 million colours) for a limitless colour range
White temperature presets: 3200K~10000K
Installed optics: 35°
LEDs average life span: >50'000h
Electronics and features
DMX channels: 12CH/48CH
PWM speed: 1000Hz. Very good for digital camera and video recording.
16bit dimming,flicker free operations
LED display
Master/Slave mode for stand-alone operations
Linear and “stepless” transition between DMX values
Cooling: Natural convection heat dissipation
Structure and Power supply
High resistance and flame retardant polymer case in black colour
3-pin and 5-pin DMX in/out XLR connectors
Internal Protection: IP33
Power cable (shuko 1,5 mt) included
Double hanging bracket suitable for safe hanging and for floor positioning
Power unit: 100-240V 50/60Hz
Max power consumption: 150W
Weight: 5 kg
Dimensions (WxHxD): 575x89x160 mm
