BY-960C 60W Beam Moving Head
Category: LED Moving Heads
Publish Time: 2018-03-30 02:09
_lit.jpg)
60W Beam Moving Head
Product Specification:
●Rate voltage: AC100V~240V 50-60HZ
●Rate power consumption: 100W
●LED qty: ※60W RGBW high power LEDs
※8x 0.5W RGBLEDs
●LED drive current: 4.5A
●Lens:94mm efficient bright PMMA lens
●Beam angle: 5°
●IP calss: IP20
●DMX modes: 15CH/17CH/33CH
●Packageing size:350x260x310mm
●Net weight: 5.1KG
●Gross weight:6.2kg
●Rate power consumption: 100W
●LED qty: ※60W RGBW high power LEDs
※8x 0.5W RGBLEDs
●LED drive current: 4.5A
●Lens:94mm efficient bright PMMA lens
●Beam angle: 5°
●IP calss: IP20
●DMX modes: 15CH/17CH/33CH
●Packageing size:350x260x310mm
●Net weight: 5.1KG
●Gross weight:6.2kg
Product Feature:
●XLR sockets input/output 3Pin
●Power input/output
●3 kinds of control model: DMX512,Sound,Master/slave
●Black plastic
●2.4inch TFT color display screen
●Display screen can be turned upside down with 180°to fit the installation in different place
●Indoor operation temperature:-20°C~ +40°C
●3 DMX modes:15CH/17CH/33CH
●dimmer:0-100% linear dimmer
●Pan/tilt:
※16bit pan/tilt fine
※Smooth and accurate locating
※Pan:540°Tilt:270°
※Pan/Tilt infinite rotation, and adjustable speed
※Memorable scan point,automatic reset after no appointed movement
※Default function in Pan/tilt
●Perfect mixing color and rainbow effect
●Strobe:0-20HZ strobe,pulse strobe,As ynchronouspulse strobe
●Perfect total dimmer
●Fan cooling(fan speed based on temperature)
●Special cooling system
●XLR sockets input/output 3Pin
●Power input/output
●3 kinds of control model: DMX512,Sound,Master/slave
●Black plastic
●2.4inch TFT color display screen
●Display screen can be turned upside down with 180°to fit the installation in different place
●Indoor operation temperature:-20°C~ +40°C
●3 DMX modes:15CH/17CH/33CH
●dimmer:0-100% linear dimmer
●Pan/tilt:
※16bit pan/tilt fine
※Smooth and accurate locating
※Pan:540°Tilt:270°
※Pan/Tilt infinite rotation, and adjustable speed
※Memorable scan point,automatic reset after no appointed movement
※Default function in Pan/tilt
●Perfect mixing color and rainbow effect
●Strobe:0-20HZ strobe,pulse strobe,As ynchronouspulse strobe
●Perfect total dimmer
●Fan cooling(fan speed based on temperature)
●Special cooling system
